8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness
8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness
8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness
8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness
8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness
8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness

8.4 Inch Industrial LCD Display – 1024×768, LVDS, 1200nits High Brightness

Quick info

  • Panel Size : 8.4inch
  • Model Number:FB084LXV122-A
  • Panel Type:TFT-LCD
  • View angel: 85/85/85/85
  • Resolution:1024 x 768
  • Interface Type: LVDS
Quote Now
DetailsAdditional Information
Product Description
  Panel Size 8.4inch
 Model Number FB084LXV122-A
 Panel Type TFT-LCD
 Aspect Ratio 4:3
 Resolution 1024 x 768
 Pixel Format RGB Vertical stripe
 Active Area 170.50 (W) × 127.87 (H)mm
 Bezel Opening
 Outline Dimension 184.5(W) x143.0 (H) x 7.25(D) mm
 Treatment Anti-Glare 3H
 View Angel 85/85/85/85
 Support Color 16.7M（6bit+FRC）
 Luminance 1200cd/m²
 Interface Type LVDS
 Operatation Temperature -20℃ ~ 75℃
 Storage Temperature -30℃ ~ 70℃
 Power Supply Votage 34V
 Current for LED Backlight 105mA
 Application Industrial, Medical, Comerical, Automotive, Security, Euipment, etc
 Sample Leadtime 7-10days
