Product Description
| Panel Size | 10.4inch |
| Model Number | FB104NXV201-A |
| Panel Type | TFT-LCD |
| Aspect Ratio | 4:3 |
| Resolution | 1024 x 768 |
| Pixel Format | RGB Stripe |
| Active Area | 210.432 (W) x 157.824 (H) mm |
| Bezel Opening | 215.4 (W) x 161.80(H) mm |
| Outline Dimension | 238.6 (W) x 175.8 (H) x 6.5(D) mm |
| Treatment | HC |
| View Angel | 80/80/80/80 |
| Support Color | 256K/16.7 M |
| Luminance | 600 cd/㎡ |
| Interface Type | LVDS |
| Operatation Temperature | -30℃ ~ 85℃ |
| Storage Temperature | -30℃ ~ 85℃ |
| Power Supply Votage | 33V |
| Current for LED Backlight | 160mA |
| Application | Industrial, Medical, Comerical, Security, Euipment, etc |
| Sample Leadtime | 7-10days |
XGA IPS TFT LCD For Industrial HMI Screens
10.4 inch TFT LCD selection often starts with the balance between screen size, data layout, and industrial readability. This panel uses 1024 × 768 XGA resolution, IPS display technology, LVDS interface support, and 600 nits luminance. Its 4:3 screen ratio gives industrial HMIs, medical devices, test equipment, and embedded systems enough vertical space for values, menus, status lists, and control pages.
1024x768 Resolution For Data-Focused Interfaces
The XGA format supports a clearer information structure than many low-resolution panels. Operators can view more lines of data, alarm prompts, system settings, and graphic elements without switching pages too often.
Key product points include:
- 10.4-inch IPS TFT LCD panel
- 1024 × 768 XGA resolution
- 600 nits high brightness
- LVDS interface support
- 4:3 display ratio
- Wide temperature project review
High Brightness For Strong Working Light
Factory equipment, medical rooms, marine systems, and railway displays may face stronger ambient light than standard office screens. The 600 nits brightness helps keep content readable in these conditions, while IPS viewing supports clearer side-angle reading.
LVDS Interface And Long-Life Backlight Planning
LVDS can support stable data transmission for embedded motherboards, ARM boards, and control systems. Before sampling, FaceLCD can help review LVDS cable details, connector direction, backlight power, operating temperature needs, and mounting space. The 10.4 inch TFT LCD can also be reviewed with a touch panel or cover glass when the project needs a complete front display assembly.
10.4inch TFT LCD
