Innolux Wide TFT LCD For Dashboard-Style Displays
Innolux 12.3 inch TFT LCD products are often chosen for wide interface layouts rather than standard square or 16:9 screens. DJ123IA-01B provides 1920 × 720 resolution, 750 nits brightness, LVDS interface support, and full viewing angle reference. This display format works well when a product needs long horizontal space for status, graphics, alerts, and control areas.
750 Nits Brightness With Wide Display Space
The 750 nits brightness helps support readability in bright cabins, equipment panels, and commercial screen environments. At the same time, the 1920 × 720 resolution gives enough room for multiple display zones across one panel.
Key product points include:
- Innolux DJ123IA-01B reference model
- 12.3-inch TFT LCD module
- 1920 × 720 resolution
- 750 nits brightness
- LVDS interface
- Full viewing angle reference
Display Planning For Vehicle And Industrial Systems
Wide LCD modules need careful mechanical planning because the long panel shape can affect cable route, mounting strength, and front cover design. Before sampling, engineers should check active area, outline size, LVDS data, backlight power, and glass structure.
Project Support Before Sampling
FaceLCD can help review panel information, sample availability, LVDS matching, backlight data, and housing fit. The Innolux 12.3 inch TFT LCD can fit automotive screens, industrial HMIs, security displays, and embedded systems that need a wide display with stronger brightness than standard indoor panels.
